Customize ePTZ Mega pixel input / CVBS output Video door phone camera Module by RS485


Customize ePTZ Video Door Phone Module  and controlled by RS485.





It connect the Mega pixel CMOS sensor. And Output is analog CVBS.

It have enough video information to do the ePTZ.


The Module embedded the hardware base Lens distortion compensation and  Keystone correction.




Hardware spec (SR1913 inside):

螢幕快照 2013-07-23 上午10.24.18 螢幕快照 2013-07-23 上午10.24.27





Size

Customize > 18mm x18 mm

Image Sensor

HM1375 Mega pixel Sensor

Video Format

NTSC / PAL

Horizontal Resolution

480 lines

Main chip

SR1913

SNR

> 50 dB

Electronic Shutter

1 s ~ 1/10000s

ePTZ

up to 10x digital zoom

Control interface

RS485 PELCO-D

White Balance

Auto

Gain Control

Auto

AE control

Auto

Mirror Function

yes

Video Output

1.0 Vp-p/75Ω

Storage Temperature

-20 ° C ~ 60 ° C

Operating Temperature

-30 ° C ~ 80 ° C




Powerful  ePTZ by RS485
