How to change the firmware (f/w) of UVC Grabber card.


The default firmware of uvc grabber card is as below.

auto detect NTSC or PAL.

Resolution is up to 640x480

MJPEG or YUV

Bulk mode

frame rate control


If you wan to let the resolution become 720x480 for NTSC  only or 720x576 for PAL only,

you must change the firmware.


NTSC ONLY

Resolution is up to720X480

MJPEG or YUV

iso mode

frame rate control


or


PAL  ONLY

Resolution is up to720X576

MJPEG or YUV

iso mode

frame rate control


How to change firmware?
Please kindly see the step by step as below.

Step 1:

To get " change firmware tools"  DL

免驅動影像擷取卡使用手冊


感謝您採買 免驅動程式影像擷取卡,
關於如何使用及簡單故障排除, 請參閱下面的連結

1.免驅動影像擷取卡的規格書

    影像品質比別人家更好,多了硬體的 3D de-interlace 和 3D Comb filter









免驅動程式 USB 3G-SDI/HD-SDI 影像擷取卡WINDOWS MAC skype ustream VJ AVENUE raspberry pi 可用






可以支持有聲音的SDI 訊號~~






為何使用 FEBON188免驅動程式 USB 3G-SDI/HD-SDI 影像擷取卡

符合標準的UVC (USB VIDEO CLASS). 對電腦來說,FEBON188 就是一個usb webcam
在 windows 和MAC OSX 都是免驅動
偽裝裝成USB WEBCAM, 可以順利騙過電腦!!
Linux , Android 等embedded 的作業系統都能用,只要將UVC 驅動程式研發進去
HDMI TO UVC!!!!
全世界最小的!!
  我們把全世界不管是PCI 或是 usb 要灌驅動程式的擷取卡作比較,
我是目前全世界最小的!!
PCBA 大小僅只有 25mm x80mm



   FEBON188 UVC SDI 擷取卡 可以用在視訊會議軟體上
不管任何的視訊軟體 SKYPE (部分SKYPE需要降版本) , QQ, V2, JoinNET, facebook 等等都能使用
視訊分享網站,如 Youtube, Ustream一定能用!











如何使用?

只有四個步驟 !!免驅動!!


STEP1: SDI擷取卡插入電腦



STEP1
STEP2: 將SDI視訊源插入SDI擷取卡上



STEP2





STEP3:在打開電腦的軟體之前,請先注意SDI 擷取卡上的LED 燈

mode1: 720P 1280X720 如果靠內側的LED 燈量,
表示HDMI 來源是1280X720 (720P)
STEP3-720P
Mode 2: 1080p 1920x1080 如果靠外側的LED 燈量,
表示HDMI 來源是1920X1080 (1080p)

STEP3-1080P



STEP4: 打開軟體 (mac裡面比如 quicktime, AMCAP and etc)








輸入/輸出的解析度對應表:

SDI 輸入 USB UVC 輸出
1920X1080P
60fps /50fps /30fps /25fps
1. MJPG
1920x1072 up to 30fps (全螢幕)
1920X1080 up to 15fps (全螢幕)
1280x720 up to 30fps (只抓取部分)
1366x768 up to 30fps
2. YUV
1920X1080 up to 5fps (全螢幕)
1280x720 up to 10fps  (只抓取部分)
1366x768 up to 10fps (只抓取部分)


1280x720P
60fps /50fps
1. MJPG
1280x720 up to 30fps (全螢幕)
1366x768 up to 30fps (只抓取部分)
2 YUV
1280x720 up to 10fps (全螢幕)
1366x768 up to 10fps  (只抓取部分)









FEBON168 UVC USB HDMI 擷取卡的實際demo



1.蘋果電腦  MAC OSX  的 quickTime Player

     http://youtu.be/lywIkEKQcRk




2. WINDOWS 7 的AMCAP

          http://youtu.be/qm84AZ4zqqs




3. iPad demo:

     必須要插入 FEBON220 UVC 無線路由器,將SDI 訊號變成無線的mjpeg stream ,

     由iPad 接收, 可以一對10台同時接收

   http://youtu.be/w2sPy0Z2dLg





4. 直接插入 NEXUS7 ( 2013 version)  android 4.3

   不用root 情況下,只能夠在 NEXUS7 (2013版本硬體)而且是 android 4.3版

    下載 APK  " dashcam"  就能夠直接使用


    http://youtu.be/T-6W_4jzM90





更多的DEMO:







買之前,請您一定要看清楚!!!

1.本產品是屬於中價位商品,如果對於影像非常挑剔,請您購買別人家的USB3.0 /PCIE hdmi 擷取卡。
因為礙於USB2.0的頻寬限制,我有經過輕微的MJPEG壓縮,
但是壓縮畢竟是無法跟完整的raw data作比較. 要很仔細很仔細雞蛋裡挑骨頭才看得出來
我只是強調我的便利性,隨插即用。我的才USB2.0,如果對於影像非常挑剔,請您不要買


2.貨物賣出,就不退貨, 但歡迎提出任何問題,我會竭盡心力的服務

大台北地區,請盡量面交,我會親自告知如何使用!

因為我已經拍了各式各樣的影片在YouTube中,本公司不接受7天鑑賞期,
下好就離手,不要後悔

更多影片demo

http://febon.blogspot.com/2014/02/febon188-uvc-usb-sdi-grabber-card-user.html





FEBON168 USB HDMI grabber card work on MAC quicktime player



MAC quicktime player not only play the video clip BUT ALSO  open live uvc webcam.

quicktime do not like windows "amcap".

Amcap can choose the all of uvc webcam paramter.

For example: resolution , video compression format, frame rate....

But...

quicktime just can choose the video resolution by video quality " high / excellent high"




FEBON168 UVC HDMI grabber card have  two version

1. 720p version

2. 1080p version


Both of two model will have difference result  in quicktime.





FEBON168 USB免驅動程式HDMI 影像擷取卡 有兩種版本,

在MAC quicktime中表現的又會是不一樣的結果

1.HDMI INPUT is up to 1920x1080P
 ( FEBON168-1080P version)

  FEBON168 will tell your hdmi source  that FEBON168 can eat 1920x1080p, 1280x720p, 1366x768p.

  Your hdmi source will output the max resolution that FEBON168 can eat.

  This is control by EDID of HDMI RX from FEBON168.

2 hdmi INPUT is up to 1280x720p
(FEBON168-720P version)


FEBON168 will tell your hdmi source  that FEBON168 can eat 1280x720p only

  Your hdmi source will output the 720p resolution that FEBON168 can eat.

  This is control by EDID of HDMI RX from FEBON168.








1.  FEBON168(720P version)  work on MAC quicktime


 FEBON168 hardware inner  LED will be light and no flah (stable)

  This signal inform you the hdmi source is output 720p and FEBON168 can successfully capture the HDMI source.

720P HDMI source is  1280X720P  50FPS  or 60fps
